Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light

Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light

Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light
Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light

Μεγάλες Εικόνας :  Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light

Λεπτομέρειες:
Τόπος καταγωγής: Jiangsu, Κίνα
Μάρκα: Crown Extra
Πιστοποίηση: ATEX,CE,ROHS,CNEX,ISO9001
Αριθμό μοντέλου: Bpy
Πληρωμής & Αποστολής Όροι:
Ποσότητα παραγγελίας min: 1PC
Τιμή: USD20-60 per pc
Συσκευασία λεπτομέρειες: Κουτί 、 Ξύλινο κουτί 、 Παλέτα
Χρόνος παράδοσης: 15 εργάσιμες ημέρες
Όροι πληρωμής: T/t
Δυνατότητα προσφοράς: 50000pcs/μήνα

Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light

περιγραφή
Μάρκα: Επιπλέον στέμμα Όνομα προϊόντος: Επικαιροποιημένα ρεύματα για την παραγωγή ηλεκτρικής ενέργειας
Μοντέλο: BPY-1200 Γωνία δέσμης: 120-140 °
Αποδοτικότητα: 100lm/w Κρίμα: RA: ≥70
CCT: 5500-6500K, άλλες θερμοκρασίες χρώματος μπορούν να προσαρμοστούν Επικυρωμένος: CNEX, EX, IP66, IEC, IECEX
Βάση: Οροφή, Φλάντζ, Κεραυνός Τείχους

Ip66 1.2M 4Ft Led Linear Explosion-Proof Lamps industrial 18-36W double tube Explosion Proof Fluorescent Light



BPY Series

Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light 0





Features:

1. Die casting aluminum shell, with high voltage electrostatic plastic-spraysurface.

2. Easy to change the tube, just remove the end cover to change.
3. Electronic ballast, improve the power factor largely, COS>0.95
4. Tempered glass lamp shade, stainless steel exposed fastener.
5. Steel pipe wiring or cable wiring


Applications


A wide range of hazardous areas where ignitable vapors, dust, moisture and corrosive elements are present
Areas requiring frequent on-and-off of lights or power cycling- no warm up time required
Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation
Other high humidity, high dust, high temperature, vapor locations




Standard Materials
Housing:Die-cast aluminum
Exterior:Stainless steel
Globe:Tempered glass




Certifications
ATEX
CNEX
CE
RoHS
ISO9001




Dimensions(In millimeter)


Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light 1



Electrical Data
Ex MarkingEx d e IIC T6 Gb/ DIP A21 TA
ClassificationGroup II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D; Zone 1, 2 & Zone 21, 22
IP DegreeIP66
Corrosion ResistantWF1
Input Voltage90-305VAC/50~60HZ or 24V DC
Battery Back-upOptional, Emergency time>90min;Charging time:24h;Starting time:0.3s
Conduit EntriesG 3/4"
Terminal≤2.5mm2
Mounting StylesPendant; Ceiling; Chain; Embedded; Wall; Stanchion




Ordering Information
Model NO.BPY-IBPY-IIBPY-III
T8Fluorescent tube20Wat30Watt40Wat
T5 Fluorescent tube14Watt21Watt28Watt
LED tube8Watt12Watt18Watt


Ip66 1.2M 4Ft Led Linear Explosion Proof Lamps Industrial 18-36W Double Tube Explosion Proof Fluorescent Light 2
Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.
